Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 9.5 | 12.0 | 1.26 | 75 | 9.4 | 7.4 | 0.787 | 0.787 | 0.779 | ||||
15 | 9.5 | 11.0 | 1.16 | 60 | 9.4 | 8.0 | 0.851 | 0.862 | 0.842 | ||||
20 | 9.5 | 11.0 | 1.16 | 45 | 9.4 | 8.9 | 0.947 | 0.950 | 0.937 | ||||
30 | 9.4 | 9.9 | 1.05 | 30 | 9.4 | 9.9 | 1.053 | 1.053 | 1.042 | ||||
45 | 9.4 | 8.9 | 0.95 | 20 | 9.5 | 11.0 | 1.158 | 1.123 | 1.158 | ||||
60 | 9.4 | 8.0 | 0.85 | 15 | 9.5 | 11.0 | 1.158 | 1.193 | 1.158 | ||||
75 | 9.4 | 7.4 | 0.79 | 0 | 9.5 | 12.0 | 1.263 | 1.263 | 1.263 | ||||
-15 | 9.5 | 11.0 | 1.16 | -15 | 9.5 | 11.0 | 1.158 | 1.193 | 1.158 | ||||
-20 | 9.5 | 11.0 | 1.16 | -20 | 9.5 | 11.0 | 1.158 | 1.123 | 1.158 | ||||
-30 | 9.4 | 9.9 | 1.05 | -30 | 9.4 | 9.9 | 1.053 | 1.053 | 1.042 | ||||
-45 | 9.4 | 8.9 | 0.95 | -45 | 9.4 | 8.9 | 0.947 | 0.950 | 0.937 | ||||
-60 | 9.4 | 8.0 | 0.85 | -60 | 9.4 | 8.0 | 0.851 | 0.862 | 0.842 | ||||
-75 | 9.4 | 7.4 | 0.79 | -75 | 9.4 | 7.4 | 0.787 | 0.787 | 0.779 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
