Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 9.6 | 14.0 | 1.46 | 75 | 9.5 | 6.0 | 0.632 | 0.632 | 0.625 | ||||
15 | 9.6 | 12.0 | 1.25 | 60 | 9.5 | 6.8 | 0.716 | 0.698 | 0.708 | ||||
20 | 9.5 | 11.0 | 1.16 | 45 | 9.5 | 7.1 | 0.747 | 0.821 | 0.740 | ||||
30 | 9.5 | 9.5 | 1.00 | 30 | 9.5 | 9.5 | 1.000 | 0.968 | 0.990 | ||||
45 | 9.5 | 7.1 | 0.75 | 20 | 9.5 | 11.0 | 1.158 | 1.136 | 1.146 | ||||
60 | 9.5 | 6.8 | 0.72 | 15 | 9.6 | 12.0 | 1.250 | 1.289 | 1.250 | ||||
75 | 9.5 | 6.0 | 0.63 | 0 | 9.6 | 14.0 | 1.458 | 1.458 | 1.458 | ||||
-15 | 9.6 | 12.0 | 1.25 | -15 | 9.6 | 12.0 | 1.250 | 1.289 | 1.250 | ||||
-20 | 9.5 | 11.0 | 1.16 | -20 | 9.5 | 11.0 | 1.158 | 1.136 | 1.146 | ||||
-30 | 9.5 | 9.5 | 1.00 | -30 | 9.5 | 9.5 | 1.000 | 0.968 | 0.990 | ||||
-45 | 9.5 | 7.1 | 0.75 | -45 | 9.5 | 7.1 | 0.747 | 0.821 | 0.740 | ||||
-60 | 9.5 | 6.8 | 0.72 | -60 | 9.5 | 6.8 | 0.716 | 0.698 | 0.708 | ||||
-75 | 9.5 | 6.0 | 0.63 | -75 | 9.5 | 6.0 | 0.632 | 0.632 | 0.625 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
