Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 7.3 | 7.5 | 1.03 | 75 | 7.2 | 6.8 | 0.944 | 0.944 | 0.932 | ||||
15 | 7.3 | 7.5 | 1.03 | 60 | 7.2 | 6.9 | 0.958 | 0.958 | 0.945 | ||||
20 | 7.3 | 7.4 | 1.01 | 45 | 7.2 | 7.0 | 0.972 | 0.977 | 0.959 | ||||
30 | 7.3 | 7.3 | 1.00 | 30 | 7.3 | 7.3 | 1.000 | 0.995 | 1.000 | ||||
45 | 7.2 | 7.0 | 0.97 | 20 | 7.3 | 7.4 | 1.014 | 1.014 | 1.014 | ||||
60 | 7.2 | 6.9 | 0.96 | 15 | 7.3 | 7.5 | 1.027 | 1.023 | 1.027 | ||||
75 | 7.2 | 6.8 | 0.94 | 0 | 7.3 | 7.5 | 1.027 | 1.027 | 1.027 | ||||
-15 | 7.3 | 7.5 | 1.03 | -15 | 7.3 | 7.5 | 1.027 | 1.023 | 1.027 | ||||
-20 | 7.3 | 7.4 | 1.01 | -20 | 7.3 | 7.4 | 1.014 | 1.014 | 1.014 | ||||
-30 | 7.3 | 7.3 | 1.00 | -30 | 7.3 | 7.3 | 1.000 | 0.995 | 1.000 | ||||
-45 | 7.2 | 7.0 | 0.97 | -45 | 7.2 | 7.0 | 0.972 | 0.977 | 0.959 | ||||
-60 | 7.2 | 6.9 | 0.96 | -60 | 7.2 | 6.9 | 0.958 | 0.958 | 0.945 | ||||
-75 | 7.2 | 6.8 | 0.94 | -75 | 7.2 | 6.8 | 0.944 | 0.944 | 0.932 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
