Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 10.0 | 11.0 | 1.10 | 75 | 9.9 | 9.4 | 0.949 | 0.949 | 0.940 | ||||
15 | 9.9 | 10.0 | 1.01 | 60 | 9.9 | 9.7 | 0.980 | 0.973 | 0.970 | ||||
20 | 9.9 | 10.0 | 1.01 | 45 | 9.9 | 9.8 | 0.990 | 0.993 | 0.980 | ||||
30 | 9.9 | 10.0 | 1.01 | 30 | 9.9 | 10.0 | 1.010 | 1.003 | 1.000 | ||||
45 | 9.9 | 9.8 | 0.99 | 20 | 9.9 | 10.0 | 1.010 | 1.010 | 1.000 | ||||
60 | 9.9 | 9.7 | 0.98 | 15 | 9.9 | 10.0 | 1.010 | 1.040 | 1.000 | ||||
75 | 9.9 | 9.4 | 0.95 | 0 | 10.0 | 11.0 | 1.100 | 1.100 | 1.100 | ||||
-15 | 9.9 | 10.0 | 1.01 | -15 | 9.9 | 10.0 | 1.010 | 1.040 | 1.000 | ||||
-20 | 9.9 | 10.0 | 1.01 | -20 | 9.9 | 10.0 | 1.010 | 1.010 | 1.000 | ||||
-30 | 9.9 | 10.0 | 1.01 | -30 | 9.9 | 10.0 | 1.010 | 1.003 | 1.000 | ||||
-45 | 9.9 | 9.8 | 0.99 | -45 | 9.9 | 9.8 | 0.990 | 0.993 | 0.980 | ||||
-60 | 9.9 | 9.7 | 0.98 | -60 | 9.9 | 9.7 | 0.980 | 0.973 | 0.970 | ||||
-75 | 9.9 | 9.4 | 0.95 | -75 | 9.9 | 9.4 | 0.949 | 0.949 | 0.940 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
