| Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
| 0 | 10.0 | 10.0 | 1.00 | 75 | 10.0 | 9.5 | 0.950 | 0.950 | 0.950 | ||||
| 15 | 10.0 | 10.0 | 1.00 | 60 | 10.0 | 9.7 | 0.970 | 0.970 | 0.970 | ||||
| 20 | 10.0 | 10.0 | 1.00 | 45 | 10.0 | 9.9 | 0.990 | 0.983 | 0.990 | ||||
| 30 | 10.0 | 9.9 | 0.99 | 30 | 10.0 | 9.9 | 0.990 | 0.993 | 0.990 | ||||
| 45 | 10.0 | 9.9 | 0.99 | 20 | 10.0 | 10.0 | 1.000 | 0.997 | 1.000 | ||||
| 60 | 10.0 | 9.7 | 0.97 | 15 | 10.0 | 10.0 | 1.000 | 1.000 | 1.000 | ||||
| 75 | 10.0 | 9.5 | 0.95 | 0 | 10.0 | 10.0 | 1.000 | 1.000 | 1.000 | ||||
| -15 | 10.0 | 10.0 | 1.00 | -15 | 10.0 | 10.0 | 1.000 | 1.000 | 1.000 | ||||
| -20 | 10.0 | 10.0 | 1.00 | -20 | 10.0 | 10.0 | 1.000 | 0.997 | 1.000 | ||||
| -30 | 10.0 | 9.9 | 0.99 | -30 | 10.0 | 9.9 | 0.990 | 0.993 | 0.990 | ||||
| -45 | 10.0 | 9.9 | 0.99 | -45 | 10.0 | 9.9 | 0.990 | 0.983 | 0.990 | ||||
| -60 | 10.0 | 9.7 | 0.97 | -60 | 10.0 | 9.7 | 0.970 | 0.970 | 0.970 | ||||
| -75 | 10.0 | 9.5 | 0.95 | -75 | 10.0 | 9.5 | 0.950 | 0.950 | 0.950 | ||||
|
|
|||||||||||||
|
|
|||||||||||||
|
|
|||||||||||||
