Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 10.0 | 9.9 | 0.99 | 75 | 10.0 | 9.2 | 0.920 | 0.920 | 0.920 | ||||
15 | 10.0 | 9.8 | 0.98 | 60 | 10.0 | 9.2 | 0.920 | 0.923 | 0.920 | ||||
20 | 10.0 | 9.8 | 0.98 | 45 | 10.0 | 9.3 | 0.930 | 0.933 | 0.930 | ||||
30 | 10.0 | 9.5 | 0.95 | 30 | 10.0 | 9.5 | 0.950 | 0.953 | 0.950 | ||||
45 | 10.0 | 9.3 | 0.93 | 20 | 10.0 | 9.8 | 0.980 | 0.970 | 0.980 | ||||
60 | 10.0 | 9.2 | 0.92 | 15 | 10.0 | 9.8 | 0.980 | 0.983 | 0.980 | ||||
75 | 10.0 | 9.2 | 0.92 | 0 | 10.0 | 9.9 | 0.990 | 0.990 | 0.990 | ||||
-15 | 10.0 | 9.8 | 0.98 | -15 | 10.0 | 9.8 | 0.980 | 0.983 | 0.980 | ||||
-20 | 10.0 | 9.8 | 0.98 | -20 | 10.0 | 9.8 | 0.980 | 0.970 | 0.980 | ||||
-30 | 10.0 | 9.5 | 0.95 | -30 | 10.0 | 9.5 | 0.950 | 0.953 | 0.950 | ||||
-45 | 10.0 | 9.3 | 0.93 | -45 | 10.0 | 9.3 | 0.930 | 0.933 | 0.930 | ||||
-60 | 10.0 | 9.2 | 0.92 | -60 | 10.0 | 9.2 | 0.920 | 0.923 | 0.920 | ||||
-75 | 10.0 | 9.2 | 0.92 | -75 | 10.0 | 9.2 | 0.920 | 0.920 | 0.920 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
