Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 7.2 | 5.6 | 0.78 | 75 | 7.1 | 5.1 | 0.718 | 0.718 | 0.708 | ||||
15 | 7.2 | 5.5 | 0.76 | 60 | 7.1 | 5.1 | 0.718 | 0.724 | 0.708 | ||||
20 | 7.2 | 5.5 | 0.76 | 45 | 7.2 | 5.3 | 0.736 | 0.735 | 0.736 | ||||
30 | 7.2 | 5.4 | 0.75 | 30 | 7.2 | 5.4 | 0.750 | 0.750 | 0.750 | ||||
45 | 7.2 | 5.3 | 0.74 | 20 | 7.2 | 5.5 | 0.764 | 0.759 | 0.764 | ||||
60 | 7.1 | 5.1 | 0.72 | 15 | 7.2 | 5.5 | 0.764 | 0.769 | 0.764 | ||||
75 | 7.1 | 5.1 | 0.72 | 0 | 7.2 | 5.6 | 0.778 | 0.778 | 0.778 | ||||
-15 | 7.2 | 5.5 | 0.76 | -15 | 7.2 | 5.5 | 0.764 | 0.769 | 0.764 | ||||
-20 | 7.2 | 5.5 | 0.76 | -20 | 7.2 | 5.5 | 0.764 | 0.759 | 0.764 | ||||
-30 | 7.2 | 5.4 | 0.75 | -30 | 7.2 | 5.4 | 0.750 | 0.750 | 0.750 | ||||
-45 | 7.2 | 5.3 | 0.74 | -45 | 7.2 | 5.3 | 0.736 | 0.735 | 0.736 | ||||
-60 | 7.1 | 5.1 | 0.72 | -60 | 7.1 | 5.1 | 0.718 | 0.724 | 0.708 | ||||
-75 | 7.1 | 5.1 | 0.72 | -75 | 7.1 | 5.1 | 0.718 | 0.718 | 0.708 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
