Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 7.3 | 7.4 | 1.01 | 75 | 7.2 | 2.7 | 0.375 | 0.375 | 0.370 | ||||
15 | 7.3 | 6.7 | 0.92 | 60 | 7.2 | 2.9 | 0.403 | 0.403 | 0.397 | ||||
20 | 7.3 | 5.9 | 0.81 | 45 | 7.2 | 3.1 | 0.431 | 0.456 | 0.425 | ||||
30 | 7.3 | 3.9 | 0.53 | 30 | 7.3 | 3.9 | 0.534 | 0.591 | 0.534 | ||||
45 | 7.2 | 3.1 | 0.43 | 20 | 7.3 | 5.9 | 0.808 | 0.753 | 0.808 | ||||
60 | 7.2 | 2.9 | 0.40 | 15 | 7.3 | 6.7 | 0.918 | 0.913 | 0.918 | ||||
75 | 7.2 | 2.7 | 0.38 | 0 | 7.3 | 7.4 | 1.014 | 1.014 | 1.014 | ||||
-15 | 7.3 | 6.7 | 0.92 | -15 | 7.3 | 6.7 | 0.918 | 0.913 | 0.918 | ||||
-20 | 7.3 | 5.9 | 0.81 | -20 | 7.3 | 5.9 | 0.808 | 0.753 | 0.808 | ||||
-30 | 7.3 | 3.9 | 0.53 | -30 | 7.3 | 3.9 | 0.534 | 0.591 | 0.534 | ||||
-45 | 7.2 | 3.1 | 0.43 | -45 | 7.2 | 3.1 | 0.431 | 0.456 | 0.425 | ||||
-60 | 7.2 | 2.9 | 0.40 | -60 | 7.2 | 2.9 | 0.403 | 0.403 | 0.397 | ||||
-75 | 7.2 | 2.7 | 0.38 | -75 | 7.2 | 2.7 | 0.375 | 0.375 | 0.370 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
