Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 10.0 | 10.0 | 1.00 | 75 | 10.0 | 3.8 | 0.380 | 0.380 | 0.380 | ||||
15 | 10.0 | 9.3 | 0.93 | 60 | 10.0 | 4.0 | 0.400 | 0.400 | 0.400 | ||||
20 | 10.0 | 8.0 | 0.80 | 45 | 10.0 | 4.2 | 0.420 | 0.443 | 0.420 | ||||
30 | 10.0 | 5.1 | 0.51 | 30 | 10.0 | 5.1 | 0.510 | 0.577 | 0.510 | ||||
45 | 10.0 | 4.2 | 0.42 | 20 | 10.0 | 8.0 | 0.800 | 0.747 | 0.800 | ||||
60 | 10.0 | 4.0 | 0.40 | 15 | 10.0 | 9.3 | 0.930 | 0.910 | 0.930 | ||||
75 | 10.0 | 3.8 | 0.38 | 0 | 10.0 | 10.0 | 1.000 | 1.000 | 1.000 | ||||
-15 | 10.0 | 9.3 | 0.93 | -15 | 10.0 | 9.3 | 0.930 | 0.910 | 0.930 | ||||
-20 | 10.0 | 8.0 | 0.80 | -20 | 10.0 | 8.0 | 0.800 | 0.747 | 0.800 | ||||
-30 | 10.0 | 5.1 | 0.51 | -30 | 10.0 | 5.1 | 0.510 | 0.577 | 0.510 | ||||
-45 | 10.0 | 4.2 | 0.42 | -45 | 10.0 | 4.2 | 0.420 | 0.443 | 0.420 | ||||
-60 | 10.0 | 4.0 | 0.40 | -60 | 10.0 | 4.0 | 0.400 | 0.400 | 0.400 | ||||
-75 | 10.0 | 3.8 | 0.38 | -75 | 10.0 | 3.8 | 0.380 | 0.380 | 0.380 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
