Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 9.5 | 13.0 | 1.37 | 75 | 9.5 | 4.3 | 0.453 | 0.453 | 0.453 | ||||
15 | 9.5 | 10.0 | 1.05 | 60 | 9.5 | 5.0 | 0.526 | 0.533 | 0.526 | ||||
20 | 9.5 | 9.1 | 0.96 | 45 | 9.5 | 5.9 | 0.621 | 0.605 | 0.621 | ||||
30 | 9.6 | 6.4 | 0.67 | 30 | 9.6 | 6.4 | 0.667 | 0.749 | 0.674 | ||||
45 | 9.5 | 5.9 | 0.62 | 20 | 9.5 | 9.1 | 0.958 | 0.892 | 0.958 | ||||
60 | 9.5 | 5.0 | 0.53 | 15 | 9.5 | 10.0 | 1.053 | 1.126 | 1.053 | ||||
75 | 9.5 | 4.3 | 0.45 | 0 | 9.5 | 13.0 | 1.368 | 1.368 | 1.368 | ||||
-15 | 9.5 | 10.0 | 1.05 | -15 | 9.5 | 10.0 | 1.053 | 1.126 | 1.053 | ||||
-20 | 9.5 | 9.1 | 0.96 | -20 | 9.5 | 9.1 | 0.958 | 0.892 | 0.958 | ||||
-30 | 9.6 | 6.4 | 0.67 | -30 | 9.6 | 6.4 | 0.667 | 0.749 | 0.674 | ||||
-45 | 9.5 | 5.9 | 0.62 | -45 | 9.5 | 5.9 | 0.621 | 0.605 | 0.621 | ||||
-60 | 9.5 | 5.0 | 0.53 | -60 | 9.5 | 5.0 | 0.526 | 0.533 | 0.526 | ||||
-75 | 9.5 | 4.3 | 0.45 | -75 | 9.5 | 4.3 | 0.453 | 0.453 | 0.453 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
