Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
0 | 7.2 | 6.3 | 0.88 | 75 | 7.2 | 6.1 | 0.847 | 0.847 | 0.847 | ||||
15 | 7.2 | 6.3 | 0.88 | 60 | 7.2 | 6.2 | 0.861 | 0.856 | 0.861 | ||||
20 | 7.2 | 6.3 | 0.88 | 45 | 7.2 | 6.2 | 0.861 | 0.866 | 0.861 | ||||
30 | 7.2 | 6.3 | 0.88 | 30 | 7.2 | 6.3 | 0.875 | 0.870 | 0.875 | ||||
45 | 7.2 | 6.2 | 0.86 | 20 | 7.2 | 6.3 | 0.875 | 0.875 | 0.875 | ||||
60 | 7.2 | 6.2 | 0.86 | 15 | 7.2 | 6.3 | 0.875 | 0.875 | 0.875 | ||||
75 | 7.2 | 6.1 | 0.85 | 0 | 7.2 | 6.3 | 0.875 | 0.875 | 0.875 | ||||
-15 | 7.2 | 6.3 | 0.88 | -15 | 7.2 | 6.3 | 0.875 | 0.875 | 0.875 | ||||
-20 | 7.2 | 6.3 | 0.88 | -20 | 7.2 | 6.3 | 0.875 | 0.875 | 0.875 | ||||
-30 | 7.2 | 6.3 | 0.88 | -30 | 7.2 | 6.3 | 0.875 | 0.870 | 0.875 | ||||
-45 | 7.2 | 6.2 | 0.86 | -45 | 7.2 | 6.2 | 0.861 | 0.866 | 0.861 | ||||
-60 | 7.2 | 6.2 | 0.86 | -60 | 7.2 | 6.2 | 0.861 | 0.856 | 0.861 | ||||
-75 | 7.2 | 6.1 | 0.85 | -75 | 7.2 | 6.1 | 0.847 | 0.847 | 0.847 | ||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
